Adjustments are neededMicroscopeTo make the image clearer, you can follow these steps:
Using a low-power lens for observation: First, find the area that needs further observation under the low-power lens, adjust it to the center, and adjust the image to the sharpest possible level.
Rotate the converter and switch to the high-power lens: When switching to a high-power lens, rotate slowly and observe from the side to prevent the high-power lens from colliding with the slide. If the high-power lens touches a slide, it means the focal length of the low-power lens is not properly adjusted and should be redone.
Adjust the focus: After switching to a high-magnification lens, observe with your left eye through the eyepiece. At this point, a somewhat unclear object is usually visible; you can move the screw of the fine regulator counterclockwise about 0.5-1 turn to obtain a clear image. Note: Never use a coarse regulator.
Adjust the lighting: If the brightness of the field of view is not suitable, you can use a condenser and aperture to adjust it.
Observation and adjustment: During observation, you can slightly rotate the fine focus screw to make the image clearer. At the same time, attention should be paid to observing the different layers and depths of the specimen.
After completing these steps, you should be able to see clearer images. It is important to be careful during operation to avoid damageMicroscopeOr samples. If you encounter difficulties, it is recommended to seek help from professionals.
